Chamber volume (L / cu ft): 85 / 3.0
Sterilization temp. (Celsius / Fahrenheit): 110 to 123 / 230 to 253.4
Melting temp. (Celsius / Fahrenheit): 60 to 100 / 140 to 212
Sterilization at 121degree Celsius (kg/cm2): 1.1 to 1.2
Gauge range in analog (Mpa): - 0.1 to 0.6
Permissible altitude (m): Up to 800
Safety:
Over temperature protector / Pressure safety valve / Over current protector
Warning alert (over temp. / low temp. / low heat / sterilization fail / low water level)
Timer: 0 to 999 min.
Dimension:
Interior (WxH) (mm / inch): 400x758 / 15.75x29.84
Exterior (W×D×H) (mm / inch): 624x672x1083/ 24.57x26.46x42.64
Exterior with exhaust tank (W×D×H) (mm / inch): 722x672x971/ 28.42x26.46x38.23
Door max. opening (W×D×H) (mm / inch): 1012x672x1095/ 39.84x26.46x43.11
Basket (DiaxH) (mm / inch): 380x330 / 14.96x12.99
Net weight (Kg / lbs): 104 / 229.28
Electrical requirements (230V, 50/60 Hz): 14.3A
Standard Accessories:
Exhaust Tank: 5L, 114x387x281mm
Step Stool, Powder Coated Steel: 500x400x250mm
Drain Bucket: 490x291x107mm
